NSK Nakanishi HES810 Milling Spindle
NSK Nakanishi HES810 Milling Spindle
Availability:
In Stock
Product SKU:
HES-7611
Prop 65
Warning
This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information on this product, please refer to the SDS file. For more information on Prop 65, please visit www.p65warnings.ca.gov.
With this NSK Nakanishi HES Spindle, you can realize the maximum speed of 80,000 rpm without rotating your machining center's main spindle. Allows for less than 0.08" diameter drilling and milling with extremely good surface finishes. BT, NT, CAT, and HSK A63 tapers are available below. Order spindle controller (NE211) Air Line Kit (AL-C1204) and motor cord separately.
• Speeds: 20,000 - 80,000 rpm
• Max. Output Power: 350 Watt
• Spindle Accuracy: within 1 µm (0.000039")
• CHA Collet Sizes: 1/8" standard, 4.0mm maximum
• Ceramic Bearings
• Cooling System: Cooling by Air, Air Line Kit is required
• Proper Air Pressure: 29PSI
• Air Consumption: 0.53CFM
• NSK Catalog Number: 9201
Included Equipment:
• CHA Collet 1/8"
• Chuck Nut (CHN-A)
• Wrench (8 x 5) & (9 x 11)
• Speeds: 20,000 - 80,000 rpm
• Max. Output Power: 350 Watt
• Spindle Accuracy: within 1 µm (0.000039")
• CHA Collet Sizes: 1/8" standard, 4.0mm maximum
• Ceramic Bearings
• Cooling System: Cooling by Air, Air Line Kit is required
• Proper Air Pressure: 29PSI
• Air Consumption: 0.53CFM
• NSK Catalog Number: 9201
Included Equipment:
• CHA Collet 1/8"
• Chuck Nut (CHN-A)
• Wrench (8 x 5) & (9 x 11)
With this NSK Nakanishi HES Spindle, you can realize the maximum speed of 80,000 rpm without rotating your machining center's main spindle. Allows for less than 0.08" diameter drilling and milling with extremely good surface finishes. BT, NT, CAT, and HSK A63 tapers are available below. Order spindle controller (NE211) Air Line Kit (AL-C1204) and motor cord separately.
• Speeds: 20,000 - 80,000 rpm
• Max. Output Power: 350 Watt
• Spindle Accuracy: within 1 µm (0.000039")
• CHA Collet Sizes: 1/8" standard, 4.0mm maximum
• Ceramic Bearings
• Cooling System: Cooling by Air, Air Line Kit is required
• Proper Air Pressure: 29PSI
• Air Consumption: 0.53CFM
• NSK Catalog Number: 9201
Included Equipment:
• CHA Collet 1/8"
• Chuck Nut (CHN-A)
• Wrench (8 x 5) & (9 x 11)
• Speeds: 20,000 - 80,000 rpm
• Max. Output Power: 350 Watt
• Spindle Accuracy: within 1 µm (0.000039")
• CHA Collet Sizes: 1/8" standard, 4.0mm maximum
• Ceramic Bearings
• Cooling System: Cooling by Air, Air Line Kit is required
• Proper Air Pressure: 29PSI
• Air Consumption: 0.53CFM
• NSK Catalog Number: 9201
Included Equipment:
• CHA Collet 1/8"
• Chuck Nut (CHN-A)
• Wrench (8 x 5) & (9 x 11)
